Description
With its 480 cold white SMD LEDs and the flash frequency adjustable from 1 to 20 Hz, the LED Super Strobe combines stroboscope, blinder and wash effects. It lets you create both dynamic stage shows and the more low-key effects in between with a single fixture. The very wide beam angle of 120° guarantees a great visual experience even from a lateral view. You can choose from three different operation modes: master-slave, stand-alone and DMX mode (1, 2 or 3 DMX channels). The metal housing ensures stability and is equipped with a mounting bracket, 3-pin DMX connectors and a P-Con input and output to connect the fixture to the mains.
Features
Strobe with 480 bright SMD 5050 LEDs and DMX
- 480 powerful LEDs SMD 5050 cold white (CW)
- Strobe effect
- Control via DMX
- Flicker-free
- With mounting bracket
- Dimmer electronic; effect speed adjustable
- Preprogrammed in LED PC-Control 512; Light Captain
- 4 digit 7-segment LED display
- Mains input and output for power linking up to 8 units
- For application areas such as: Clubs/dancing school; stage; theater; mobile djs / entertainer
- Very quiet working noise
- Application possibility: Suspended
Package contents
- 1 x spotlight, 1 x power cord, 1 x mounting bracket, 2 x knurled screw, 2 x washer, 1 x user manual
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 75 W |
| Lamp type: | LED lamp |
| LED type: | 480 x SMD 5050 cold white (CW) |
| Flash rate: | 1 – 20 Hz |
| DMX channels: | 1; 2; 3 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Control: | DMX |
| Preprogrammed in: | LED PC-Control 512; Light Captain |
| Projection: | Flicker-free |
| Beam angle (1/2 peak): | 120° |
| Color temperature: | 6500K |
| Attachment system: | Mounting bracket |
| Display type: | 4 digit 7-segment LED display |
| Dimensions: | Width: 46 cm Depth: 8 cm Height: 25,5 cm |
| Weight: | 3,75 kg |
| Noise classification: | Class 1 (very slight noise, suitable for noise-sensitive environments) |
| Power cord | |
| Cable construction: | 3 x 1 mm² H05VV-F |
| Cable length: | Approx. 1,5 m |
| Mounting bracket | |
| Diameter mounting holes: | 3 x Ø11mm; 2 x Ø8mm |
| Material: | Metal, 2 mm |
| Legal specifications | |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397656138 | 4,15 kg | 45cm x 15,5cm x 30cm |
