Description
Features
PAR spot with warm white 100 W COB LED and manual zoom
- Light performance comparable to a traditional 1000 W halogen spot light
- Homogeneous light distribution
- 1 powerful LED 100 W COB (chip-on-board) warm white (WW)
- The device is cooled by cooling fan
- Control via DMX
- Flicker-free
- Very high color rendering index (CRI)
- With mounting bracket
- 4 digit 7-segment LED display
- For application areas such as: Theater; Trade fair and shop fitting; stage; wedding/gala/events
- Dimmer speed (step response) adjustable; pulse-width modulation variable; Gamma correction adjustable
- Strobe effect
- Preprogrammed in Light Captain; Light´J
- Mains input and output for power linking up to 8 units
- Application possibility: Suspended; on stand
Package contents
- 1 x spotlight, 1 x user manual, 1 x power cord, 1 x XLR cable, 1 x filter frame, 1 x mounting bracket, 2 x knurled screw, 2 x washer
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 110 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Power output: | P-Con (gray), mounting version |
| Lamp type: | LED lamp |
| LED type: | 1 x 100 W COB (chip-on-board) warm white (WW) |
| DMX channels: | 1; 2; 3 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Cooling fan |
| Control: | DMX |
| Preprogrammed in: | Light Captain; Light´J |
| Projection: | Flicker-free |
| Beam angle (1/10 peak): | 15 – 48° |
| Color temperature: | 3000K |
| Color rendering index (CRI): | 90 Ra |
| Illuminance in Lux (lx): | Narrow warm white (WW) 3m: 14535 lx, 6m: 3666 lx Wide warm white (WW) 3m: 2134 lx, 6m: 614 lx |
| Housing color: | White |
| Attachment system: | Mounting bracket |
| Display type: | 4 digit 7-segment LED display |
| Dimensions: | Width: 26 cm Depth: 43,5 cm Height: 37,5 cm |
| Weight: | 3,80 kg |
| Noise classification: | Class 2 (slight noise) |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397694826 | 4,80 kg | 50cm x 38cm x 38cm |
