Description
Features
Art-Net and USB interface for output of 8162 channels
- Can receive and process up to 512 DMX channels
- Can transmit up to 8162 DMX channels
- The device is cooled by passive convection cooling
- Control via Art-Net
- Built with NEUTRIK connector
- The device can be connected via USB to the PC
- (19″) 48.3 cm rack installation 2 U
- Made in Germany
- The device can be connected via RJ-45 etherCON (F) mounting version to the PC
- For further information about this product, please refer to the Data Sheet under “Downloads”
Technical specifications
| Power consumption: | 5,00 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| DMX channels: | Input 512 Output 8162 |
| DMX input: | 1 x 5-pin XLR (M) mounting version |
| DMX output: | 16 x 5-pin XLR (F) mounting version |
| Network connection: | Protocol: Art-Net 3 via 1x RJ-45 etherCON (F) mounting version |
| Cooling: | Passive convection cooling |
| Control: | Art-Net |
| USB port: | USB 2.0, type B |
| Use of brands: | Built with NEUTRIK connector |
| PC connect: | Via USB Via RJ-45 etherCON (F) mounting version |
| Housing design: | (19″) 48.3 cm rack installation 2 U |
| Dimensions: | Width: 48,3 cm Depth: 7,6 cm Height: 8,9 cm |
| Weight: | 2,27 kg |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4260263421158 | 2,75 kg | 54,5cm x 17,5cm x 10,5cm |
